SPECIFICATIONS:
Input Frequency:3.4-4.2GHz
Output Frequency:950-1750MHz
Focal Length(cm):57.0
L.O Frequency: 5.15GHz¡À1MHz
L.O.Phase Noise:
-55dBc/Hz@1KHz(OFFSET)
-85dBc/Hz@10KHz(OFFSET)
-105dBc/Hz@100KHz(OFFSET)
Polarity:SWITCHED H and V
Conversion Gain:65dB(typ)
Noise Figure:13¡ãK(min)
Gain Flatness:¡À0.5dB/36 MHz
Image Rejection:50dB
Output V.S.W.R:2.5:1
Operating Termperature: -40oC~+60o C
DC Supply Voltage:10-14.5V(V),15.5-25V(H)
Supply Current:150 mA(MAX)
Rf Input Connecter:WAVE GUIDE WC-229
If Output Connecter:"F"TYPE FEMALE 75&Omega
|
