SPECIFICATION:
RFInput:
Input Frequency Range: 12.25~12.75GHz
IF Output:
Output Frequency Range: 950~1450MHz
Output Connector Type: 75&Omega F
Female Connector
Output VSWR: 2.5:1(max)
Local Oscillator:
L.O Frequency: 11.30GHz
L.O.Frequency -55dBc/Hz(@1KHz)
Phase Noise:
-80dBc/Hz(@10KHz)
-100dBc/Hz(@100KHz)
Conversion Gain: 50dB(min.) 60dB(max)
Gain Flatness
(AcrossAny27MhzSegment): ¡À0.5dB (typ.)
Output Power@1dB Gain Compression: 0dBm
Noise Figure: 0.7dB(typical)
Image Rejection: 45dB(min.)
Cross POL.Isolation: 20dB(min.)
DC Current Consumption: 130mA(MAX)
Operating Voltage:
(1)Vertical:11.5~14.0Vdc
(2)Horizontal:16.0~19.0Vdc
(3)HingBand:Continuous22KHz¡À4KHz
Operating Temperature Range:-40oC~+60o C
|
